Exeter sits on a geological boundary that keeps pavement engineers honest. The western half of the city rests on the Permian-era Culm Measures, a sequence of interbedded mudstones and sandstones that weathers fast when exposed to Devon's 800mm of annual rainfall. The eastern side, toward Sowton and the M5 corridor, spreads across alluvial floodplain deposits where the water table sits barely a metre below finished grade in wet winters. This contrast means a single pavement cross-section lifted from a manual will not work city-wide. We design flexible pavement structures that account for the subgrade CBR of the specific site, using granular capping layers, geogrid reinforcement, and calibrated bituminous bound materials. For projects near the Exe flood channel, we pair pavement design with in-situ permeability testing to confirm drainage coefficients before finalising layer thicknesses.
On Exeter's floodplain soils, ignoring a 2 percent CBR subgrade adds a full resurface cost within five years—differential heave cracks bitumen faster than traffic loading.
Scope of work in Exeter
Critical ground factors in Exeter
A routine mistake we see on Exeter greenfield sites is the contractor laying the capping layer directly onto a softened subgrade without a proof roll. The Culm shales break down to a slurry within hours of rain, and if you trap that moisture beneath 300mm of granular fill, the pavement pumps water upward during the first freeze-thaw cycle. Cracks appear in the binder course within two winters. We require a proof roll witnessed by the geotechnical engineer, a soaked CBR re-test at formation level if the weather window was poor, and a 24-hour drainage test on the sub-base before the first asphalt paver arrives. On the alluvium south of Countess Wear, we also specify lime stabilisation of the upper 300mm to lift the CBR above 5 percent before capping—skipping this step turns a 20-year design life into an eight-year maintenance headache.
Our services
Our Exeter pavement team works closely with the geotechnical lab so that every design parameter is measured, not assumed. We deliver the full package from subgrade investigation through to final overlay specification.
Subgrade Assessment & CBR Testing
On-site dynamic cone penetrometer profiles correlated to laboratory soaked CBR, plus moisture condition value determination on the Culm Measures clays to set the optimum capping thickness.
Full Pavement Thickness Design
Layer-by-layer design output following DMRB CD 226 for flexible pavements, with material specifications for the sub-base, binder course (DBM50 or HDM50), and thin surface course system, including asphalt concrete recipe validation.
Common questions
What is the typical design life for a flexible pavement on Exeter's alluvial soils?
We design to a 40-year structural life for the foundation and sub-base, with a 15 to 20-year surfacing cycle. On the Exe floodplain deposits, achieving this requires a stabilised capping layer and careful drainage detailing; without those, you are looking at surface course replacement within 8 to 10 years due to seasonal deformation.
How much does a flexible pavement design package cost for a road project in Exeter?
A complete design package including subgrade investigation, lab CBR testing, and thickness design report typically falls between £1,250 and £3,600, depending on the number of boreholes, the length of the alignment, and whether lime stabilisation mix designs are required.
Do you use mechanistic-empirical methods or just the DMRB catalogue for Exeter sites?
We use both. For standard residential access roads we apply the DMRB CD 226 catalogue method. For heavily trafficked routes or sites with marginal subgrades—common in the Monkerton and Newcourt areas—we run a mechanistic analysis using KENLAYER or similar software to model tensile strain at the bottom of the asphalt and compressive strain on the subgrade, validating the catalogue output against actual material moduli from our lab.
